HAIMER – Shrink Fit Machines – Power Clamp Profi Line
The Profi Line offers the full range of performance and is unbeatable in efficiency. High performance coils, contact cooling and rotary table guarantee simultaneous shrinking and cooling in record time. No wishes remain unfulfilled.
The machines of the Profi Line work both the standard coils and the intelligent and comfortable NG coils. Of course, the equipment recognizes each coil and chooses the correct shrink fit parameters automatically.
The shrink fir units of the Profi Line form a modular system. The start-up machine Power Clamp Economic can gradually be upgraded to the high performance Power Clamp Comfort NG.
The high-end shrink fit machine Power Clamp Premium Plus complements the Profi Line. It stands for absolute process reliability with two separate electronic units and two coils.
Available Models
Technical Specifications
| Mains voltage | 13 kW. |
| Maximum length of shrink fit chuck | 510 mm. |
| Dimensions (WxDxH) | 860x600x990 mm. |
| Weight | 50 Kg. |
| Tool diameter | 3-32 mm. |
Technical Specifications
| Mains voltage | 13 kW. |
| Maximum length of shrink fit chuck | 570 mm. |
| Dimensions (WxDxH) | 860x600x990 mm. |
| Weight | 50 Kg. |
| Tool diameter | 3-32 mm. |
Technical Specifications
| Mains voltage | 13 kW. |
| Maximum length of shrink fit chuck | 510 mm. |
| Dimensions (WxDxH) | 860x600x990 mm. |
| Weight | 70 Kg. |
| Tool diameter | 3-32 mm. |
Technical Specifications
| Mains voltage | 13 kW. |
| Maximum length of shrink fit chuck | 570 mm. |
| Dimensions (WxDxH) | 860x600x990 mm. |
| Weight | 70 Kg. |
| Tool diameter | 3-32 mm. |
Technical Specifications
| Mains voltage | 13 kW. |
| Maximum length of shrink fit chuck | 510 mm. |
| Dimensions (WxDxH) | 860x600x990 mm. |
| Weight | 70 Kg. |
| Tool diameter | 3-32 mm. |
Technical Specifications
| Mains voltage | 13 kW. |
| Maximum length of shrink fit chuck | 570 mm. |
| Dimensions (WxDxH) | 860x600x990 mm. |
| Weight | 70 Kg. |
| Tool diameter | 3-32 mm. |
Technical Specifications
| Mains voltage | 13 kW. |
| Maximum length of shrink fit chuck | 570 mm. |
| Dimensions (WxDxH) | 860x600x990 mm. |
| Weight | 85 Kg. |
| Tool diameter | 3-32 mm. |
Technical Specifications
| Mains voltage | 20 kW. |
| Maximum length of shrink fit chuck | 550 mm. |
| Dimensions (WxDxH) | 860x600x990 mm. |
| Weight | 85 Kg. |
| Tool diameter | 3-50 mm. |
Technical Specifications
| Mains voltage | 33 kW. |
| Maximum length of shrink fit chuck | 535 mm. |
| Dimensions (WxDxH) | 1600x850x2300 mm. |
| Weight | 550 Kg. |
| Tool diameter | 3-50 mm. |
Key Features
HAIMER – Shrink Fit Machines | Power Clamp Economic
- With standard coil V2008 and interchangable stop discs.
- Single chuck version.
- Without cooling.
HAIMER – Shrink Fit Machines | Power Clamp Economic NG
- With intelligent NG coil.
- Single chuck version.
- Without cooling.
HAIMER – Shrink Fit Machines | Power Clamp Economic Plus
- With standard coil V2008 and interchangable stop discs.
- Single chuck version.
- With integrated contact cooling.
HAIMER – Shrink Fit Machines | Power Clamp Economic Plus NG
- With intelligent NG coil.
- Single chuck version.
- With integrated contact cooling.
HAIMER – Shrink Fit Machines | Power Clamp Comfort
- With standard coil V2008 and interchangable stop discs.
- Rotary table with 3 stations.
- With integrated contact cooling.
HAIMER – Shrink Fit Machines | Power Clamp Comfort NG
- With intelligent NG coil.
- Rotary table with 3 stations.
- With integrated contact cooling.
HAIMER – Shrink Fit Machines | Power Clamp Preset NG
- With intelligent NG coil.
- Single chuck version.
- With vertical stop for length presetting.
- With integrated contact cooling.
HAIMER – Shrink Fit Machines | Power Clamp Profi Plus NG
- With intelligent NG coil (13 kW).
- Rotary table with 3 stations.
- With integrated contact cooling.
HAIMER – Shrink Fit Machines | Power Clamp Premium Plus
- With intelligent coil VS32-M and 20 kW coil.
- Integrated contact cooling with six cooling bodies.
- Attachement of the cooling bodies at linear guides.
- Centered move-down of the cooling bodies onto the tool holder.
- No damage at the edges of the cutting tool.
- Automatic move-up of the cooling bodies after the termination of the cooling process (temperature-time controlled).
- Two length presetting units with height stop.
Key Industries
- Electronics
- Semiconductor, Solar & Electronics
- Automotive
- Die & Mould
- Machinery & Manufacturing
Brand
HAIMER is a family run, medium size company located in Igenhausen, Bavaria near Augsburg, Germany. We design, produce and sell innovative, high precision products for metal cutting as well as for other branches including automotive, aerospace, energy, rail and general machining. In addition to our large offering of tool holders in all popular interfaces and lengths, including our shrinking and balancing machines, as well as our 3-D Sensors, solid carbide cutting tools, our product offering now also includes tool presetting machines.
