Nakamura-Tome – ATC Multitasking Machine – MX-100
The Nakamura-Tome MX-100 is a compact, high-precision multitasking turn-mill center designed to meet the rigorous demands of modern manufacturing. Combining the capabilities of both a machining center and a turning center, this state-of-the-art machine offers advanced software, smart features, and exceptional flexibility. With its compact footprint, the MX-100 maximizes productivity while maintaining precision, making it ideal for a wide range of parts and industries.
Technical Specifications
| φ51mm | Φ65mm (op.) | |
| Max. turning diameter | 305 mm | |
| Max. turning length | 834 mm | |
| Distance between spindles | Max.1000 mm / min.230 mm | |
| Bar capacity(φ) | 51 mm | 65 mm (only L) |
| Chunk size | 6″,8″ | |
| Spindle speed | 6,000 min-1 | 4,500 min-1 |
| Left Spindle motor | 11/7.5 kW | 15/11 kW |
| Right Spindle motor | 11/7.5 kW | |
| Floor space | height: 2,662 mm width: 4,350 mm depth: 2,795 mm | |
Key Features
- Perfection and flexibility: deliver flawless performance with the flexibility to handle complex multitasking operations efficiently.
- Solid Performance: Ensures reliable and efficient operations across various machining tasks.
- High speeds: Spindle speed12,000min-1 (op. 20,000min-1)
- Y-Axis Travel: Provides ±105 mm travel for versatile machining without rotating the C-axis.
- Compact Floor Space: Requires only 4,350mm x 2,795mm, including the chip tank.
- Eco-Friendly Design: Energy-efficient components minimize environmental impact.
- Advanced Software and Smart Features: Equipped with intelligent software to maximum performance.
Brand
DKSH has proudly been the authorized distributor of Nakamura-Tome to Korean market since 2024. Founded in 1960, Nakamura-Tome is committed to reducing the complexity of manufacturing by providing innovative solutions. Nakamura-Tome is known for pioneering multi-tasking machines that integrate advanced machining functions, especially in the development and sale of CNC machine tools, glass processing machines, and related peripherals.
